Gandy Dancer: double worm-gear motor

T

ThomasDadDurham

Really Useful Engine
Country flag
I had a Bachmann Christmas Gandy Dancer that ran (with a great deal of noise) last year. This year it stopped and on breaking it down to clean and test, the motor is completely gone. It just smokes if powered. All the threads I've searched here and elsewhere concern the 'rubber band drive' type. Mine is a double-worm-gear type. There must be somewhere I can get a motor of this size or type, OR even just roughly the same size that doesnt get in the way of the motion gears, and I can rebuild the holder with plasticard.

The Bachmann parts site and all other parts sites are of course, useless, as there's no information on size at all. The interior of the Gandy Dancer is pretty tight so I need something close if not identical. Anyone seen any other motors anywhere that are this sort of size and double ended?

I'm debating making the entire thing battery powered, but first I need to get a motor I can fit in there.

20241211_105746 (Small).jpg20241211_105732 (Small).jpg20241211_110319 (Small).jpg20241211_110304 (Small).jpg

Although they are pretty rubbish at it these days. - IMHO, obviously..

Have you contacted Bachmann Europe?

Telephone 01455 245 575 ; Email service@bachmann-europe.co.uk

There webby-site is undergoing maintenance, so a call will presently be less frustrating.

PhilP

ThomasDadDurham said:
I had a Bachmann Christmas Gandy Dancer that ran (with a great deal of noise) last year. This year it stopped and on breaking it down to clean and test, the motor is completely gone. It just smokes if powered. All the threads I've searched here and elsewhere concern the 'rubber band drive' type. Mine is a double-worm-gear type. There must be somewhere I can get a motor of this size or type, OR even just roughly the same size that doesnt get in the way of the motion gears, and I can rebuild the holder with plasticard.

The Bachmann parts site and all other parts sites are of course, useless, as there's no information on size at all. The interior of the Gandy Dancer is pretty tight so I need something close if not identical. Anyone seen any other motors anywhere that are this sort of size and double ended?

I'm debating making the entire thing battery powered, but first I need to get a motor I can fit in there.

View attachment 335774View attachment 335775View attachment 335776View attachment 335777
Click to expand...
That looks very much like the sort of motor you'd get in an 00/H0 loco - 5 pole skew-wound.

You can get miniature gear pullers (on Amazon and other sites) albeit of dubious quality, but I have successfully pulled a few worm gears off. Measure the diameter of the shaft, and see if you can locate a 12v motor of suitable dimensions - you may have to be a bit persistent with the internet searching

HO loco motor is the right length and width but is 18mm thick against your 12mm.
This thing is corroded and axles don't move. Sorry but don't remember what it was out of. Not used HO in decades.


Attachments

  • HO_Motor2.jpg
    49.2 KB · Views: 0
Rhinochugger said:
That looks very much like the sort of motor you'd get in an 00/H0 loco - 5 pole skew-wound.

You can get miniature gear pullers (on Amazon and other sites) albeit of dubious quality, but I have successfully pulled a few worm gears off. Measure the diameter of the shaft, and see if you can locate a 12v motor of suitable dimensions - you may have to be a bit persistent with the internet searching
Click to expand...

It absolutely is the one they use in HO locos, which google image searches confirmed, but Bachmanns parts website is terrible. I'd need to trawl through 700+ search results. They wont even advise either.
I think I'm going to have to email all the UK repairs and parts dealers. Good call on the gear puller, I'll have to get one.

ThomasDadDurham said:
It absolutely is the one they use in HO locos, which google image searches confirmed, but Bachmanns parts website is terrible. I'd need to trawl through 700+ search results. They wont even advise either.
I think I'm going to have to email all the UK repairs and parts dealers. Good call on the gear puller, I'll have to get one.
Click to expand...
Have a little trawl through evilbay - I've bought the odd motor from there, even if it comes from China. It's sometimes hard work finding the dimensions, but you might pick a winner.

Shaft diameter is the biggie, and there are shafts (and gears) commonly sized at 2mm and 2.3mm (among others) the tricky bit being defining the difference. I resorted to an old, imperial caliper gauge - there was some discussion on here, but I think it was in the coffee shop rather than a dedicated thread.

Chuck Hanson said:
In the third pic it looks like the carbon brush that the black wire goes to is gone? Can you open the holder and remove the brushes or is it a sealed unit?
Click to expand...
Well spotted - I'm not sure how easy it would be to get the motor back together :oops: It appears to rely on bending the metal parts over - usually something that works once only :mm:

Years ago, a friend of my father's spent a whole evening fashioning a carbon brush for one of my N gauge locos out of a piece of pencil lead, with ultimate, resounding success.

Chuck Hanson said:
In the third pic it looks like the carbon brush that the black wire goes to is gone?
Click to expand...
First pic too, now I know what to look for!

Yes, that is undoubtedly a 'standard' bachmann motor, probably used in an HO/OO diesel. I've done a similar swap with a Kader motor in the Bachmann tram.

In my experience, those brass brush holders are just a push fit in the nylon end frame/bracket. Try getting a slim screwdriver under the head or the brass that the wire is soldered to, and try a little leverage. You can also try a big screwdriver between the commutator and the brush holder inside the motor, but you can do more damage that way if you aren't careful.

You can fettle a brush from any carbon wheel pickup - the ones used on Aristo or USAT coaches tend to be bigger, but they are soft.

Incidentally, if you want to test all this, apply power to the 2 motor leads, and stick a screwdriver in the gap between the brush holder and the commutator, not touching anything else. It will act as a crude brush and the motor should try to spin. Don't do it for long!

Last edited:
I am going thru the same drill with a friends Bachmann Hand Car. I found a 5 pack of this motor on AliExpress (which I just found out they only sell them in a 10 pack now, about $2 US each with shipping). The shaft matches Bachmann 1.5mm diameter and hopefully is long enough for a stable mount and with enough power. I used a 25 year old slot car gear puller to remove the gear. More later.
